Smart Card Connector

• 8 friction contacts - ISO location
• 100,000 insertion cycles
• EMV Level 1 mechanically compliant
• Embossed smart cards supported

Human interface

• LED one color (green), dual state (blinking: waiting card insertion; ON: card reading / writing)

Cable/Power Supply

• USB reader
  • Cable 1,5 m long
  • USB 2.0 type A connector
  • Power supply thru USB port
  • Maximum operating current: 100mA
  • Operating voltage 4.7 – 5.3V

Standards / Certifications

• ISO/IEC 7816-1,2,3,4: IC Cards with contacts
• EMV Terminal Level 1 version 4.1
• Mondex ChipSafe Plus Purse 2 (CT30)
• Microsoft Windows Hardware Quality Labs (WHQL), Windows Logo Program WLP 2.0
• USB 2.0 Full speed certified (USB readers listed on usb.org website)
• CCID - Chip Card Interface Device 1.1 (USB & ExpressCard readers)

Operating Systems

• Up to Windows 8
• Win CE 4.1, 4.2, 5.0, 6.0 (USB readers)
• Linux Kernel 2.6 and higher
• Mac OS X Panther, Tiger, Leopard 32 editions (USB readers)
• Support for Solaris, XP embedded (USB readers)
